WHERE Quality IS MEETING THE DESIGN REQUIREMENTS

Our PCB layout artists  are CID+ certified and have over 25 years experience using Protel / Altium Designer tool sets.

Our goal is to get you through the full design flow from circuit design (if needed), schematic entry, PCB design layout to documentation and fabrication.

Expertise of service includes:

• Schematic capture
• Library Development
• Rules driven multi-layer design
• Hand placement
• Hand routed (Auto when needed)
• Detailed BOM Export in Excel
• Assembly Drawings in PDF form
• Fabrication Drawings in PDF form
• Fabrication Files (Gerber files in RS274X and PDF, Pick and place in ASCII, Drill file in Excellon format
• STEP File of final device
• Micro BGA, Micro Vias, Blind/Buried Vias, Vias in pad
• Mixed analog, digital
• Differential impedance control
• Controlled impedance
• Switching power supplies
• Thermal dissipation management

 We consider Altium to be  the most versatile circuit board design package available. We can import design files from:

• All previous versions of Protel / Altium
• P-CAD Tangp PCB ASCII files (*.pcb) P-CAD V16 or V17 Binary Schematic design files (*.sch) P-CAD V16 or V17 ASCII Schematic design files (*.sch) P-CAD V15, V16, or V17 Binary PCB design files (*.pcb) P-CAD V15, V16, or V17 ASCII PCB design files (*.pcb) P-CAD V16 or V17 Binary Library files (*.lib) P-CAD V16 or V17 ASCII Library files (*.lia) P-CAD PDIF file (*.pdf)
• Eagle: EAGLE Schematic (*.sch) EAGLE PCB (*.brd) EAGLE Library (*.lbr)
• OrCAD (UP to V17.2): OrCAD Capture Designs (*.dsn) OrCAD Capture Libraries (*.olb) OrCAD Layout PCB documents (*.max) OrCAD PCB Libraries (*.llb) OrCAD CIS Configuration file (*.dbc) OrCAD SDT (*.sch)
• PADS (up to VX2.x): OrCAD Capture Designs (*.dsn) OrCAD Capture Libraries (*.olb) OrCAD Layout PCB documents (*.max) OrCAD PCB Libraries (*.llb) OrCAD CIS Configuration file (*.dbc) OrCAD SDT (*.sch)
• DxDesigner (up to VX2.x): DxDesigner Designs and Libraries
• Expedition (up to VX2.x): Expedition files (*.pcb, *.lib)
• CADSTAR (up to V2018): CADSTAR Schematic Archive (*.csa) CADSTAR PCB Archive (*.cpa) CADSTAR Part Library (*.lib)

We can export design files to:

• Protel: 2.8 ASCII
• P-CAD: ASCII PCB
• OrCAD: OrCAD SDT Schematic (*.sch) OrCAD v7 Capture Design (*.sch)
• PADS: Logic 5
• We will default to the standard Altium output files unless otherwise requested.

Our Electrical Engineers can help. They have over 30 years experience in circuit design including but not limited to:

•  FPGA VHDL (Verilog),
• communication interfaces (RS 232, RS485, I2C, SPI)
• Embedded Micro Applications
• Low to High power LED drive
• Boost / Buck power conversion
• Brushless DC and Stepper drive
• EMI and EMC compliance
